Overview

St800 Fireproof Antistatic Steel Cord Conveyor Belt can ensure the best performance even under severe pressure conditions. Its excellent design guarantees high tensile strength and excellent impact resistance. Secondly, our belts are wear-resistant, corrosion-resistant, corrosion-resistant and heat-resistant. Because of the above performance, it has a long service life and hardly needs maintenance. Finally, our products are cheap and good, and are deeply loved by customers. The fundamental reason for us to win customers trust is to meet customers needs to the greatest extent.

Features
St800 Fireproof Antistatic Steel Cord Conveyor Belt will not produce violent vibration or noise during transportation.

The product is resistant to wear, corrosion, chemical corrosion and high temperature, so its service life is very long.
It is also flame retardant and anti-static, so it is not easy to ignite, spontaneously ignite or conduct electricity.

The reinforcement framework has excellent hardness and rigidity, thus providing the maximum guarantee for the stable operation of the conveyor belt.

Details of product

Origin: China

Basic information

Specification: ST800

size: width: 300-2300mm

Origin: China

Specifications

Conveyor Belt specification strength	ST 630	ST 800	ST 1000	ST 1250	ST 1600	ST 2000	ST 2500	ST 3150	ST 3500	ST 4000	ST 4500	ST 5000	ST 5400
Longitudinal tensile strength	630	800	1000	1250	1600	2000	2500	3150	3500	4000	4500	5000	5400
Maximum nominal diameter of steel cord mm	3.0	3.5	4.0	4.5	5.0	6.0	7.2	8.1	8.6	8.9/9.1	9.7	10.9	11.3
The distance between the steel cord	10	10	12	12	12	12	15	15	15	15/17	16	17	17
Thickness of up cover rubber	5	5	6	6	6	8	8	8	8	8/8	8	8.5	9
Thickness of down cover rubber	5	5	6	6	6	6	6	8	8	8/8	8	8.5	9
Quality	18	19.5	21.5	22.2	26.1	33.1	35.3	41.1	45	45/45	51	59	62
Width of conveyor belt	Number of wire ropes
800	75	75	63	63	63	63	50	50
1000	95	95	79	79	79	79	64	64	64	64/56	59	55	55
1200	113	113	94	94	94	94	76	76	77	77/68	71	66	66
1400	133	133	111	111	111	111	89	89	90	90/79	84	78	78
1600	151	151	126	126	126	126	101	101	104	104/91	96	90	90
1800		171	143	143	143	143	114	114	117	117/108	109	102	102
2000			159	159	159	159	128	128	130	130/114	121	113	113
2200						176	141	141	144	144/125	134	125	125
2400						193	155	155	157	157/137	146	137	137
2600						209	168	168	170	170/148	159	149	149
2800									184	184/160	171	161	161
